QNF360 Biscuit On Edge Packing Machine
This machine is the replacement product of our QNF360 model. This tray-less box packaging machine is controlled by servo motor, which further enhances the degree of automation of the machine, makes its performance more stable and reliable, and makes its operation easier.
Category:
On Edge Biscuit Packaging Machine
Product Overview
This machine is the replacement product of our QNF360 model. This tray-less box packaging machine is controlled by servo motor, which further enhances the degree of automation of the machine, makes its performance more stable and reliable, and makes its operation easier. The most significant feature is that it is very simple to change the size of packaged products.
Usage
It is suitable for the large packaging of multiple cookies without tray collection, square, round, oval and other shapes of cookies are available.
Main technical parameters
|
Packaging capacity |
30-100 packages/minute (according to the packaging film material, thickness and packaging specifications to determine) |
|
Packaging specifications |
length 100-240mm, width 40-80mm, height 40-70mm |
|
Machine size |
main machine part 4020mm*1150mm*1840mm |
|
Feeding part |
3100*580mm*1130mm |
|
Total installed capacity |
5.2KW, single-phase 220V, 50Hz |
|
Total weight |
1200kg |
|
Packaging materials |
paper/PE, OPP/PE, OPP/AL/PE and other packaging materials suitable for heating and sealing. |
Mechanical Characteristics
► The overall design of the mechanical structure is simple and reasonable, easy to operate and adjust.
► The use of clamping and transporting mechanism solves the problem of the complicated size change of different length items and the disadvantage of inverted cake completely and reliably.
► The longitudinal sealing device adopts three pairs of traction wheels to ensure high speed sealing, stability and beauty.
► The delicate automatic feeding device can accurately put the packages into the main machine to enter the packing and sealing.
► Packaging size adjustment is convenient and quick.
Electrical Characteristics
► Film feeding and feeding adopt digital servo motor control system.
► The feeding part adopts motion control unit, synchronized feeding, accurate and automatic memory.
► Frequency conversion speed control is convenient, accurate and reliable.
► Automatic positioning of color table tracking point and automatic label following.
► Packing bags are automatically measured and memorized.
Packaging display
